Connect the corresponding cables into sections 1 and 2 on your new 5168N.

• Ethernet cables can be connected to any Local Ethernet port (section 2).



Ensure that you write down the new wireless credentials which are located on the side of the 5168N (section 1). The SSID refers to the new Wireless Network name that you will be connecting to and the Wi-Fi Key is the new wireless password that you will be using.

• If you are using Bell MTS Whole Home Wi-Fi Pods continue to connect to the same Wireless Network name as you did prior.
• If you need help with creating a custom Wi-Fi network click here
• Click on the links if you need help connecting your computer or mobile device to the Wi-Fi.



• Avoid mixing up the Ethernet cables in sections 2 and 3.



Connect the corresponding cables into sections 1 and 2 on your new 5168N.

• Ethernet cables can be connected to any Local Ethernet port (section 1).



Ensure that you write down the new wireless credentials which are located on the side of the 5168N (section 1). The SSID refers to the new Wireless Network name that you will be connecting to and the Wi-Fi Key is the new wireless password that you will be using.

• If you are using Bell MTS Whole Home Wi-Fi Pods continue to connect to the same Wireless Network name as you did prior.
• If you need help with creating a custom Wi-Fi network click here
• Click on the links if you need help connecting your computer or mobile device to the Wi-Fi.



• If there is a coaxial cable in the cable port (section 2) unscrew it.



Connect the corresponding cables into sections 2 and 3 on your new 5168N.

• Ethernet cables can be connected to any Local Ethernet port (section 3).
• If you have a coaxial cable connect it to the cable port (section 1).



Go to each individual set-top box, starting with the PVR (VIP1216, VIP2262 or VIP5662). Press and hold the Power button (section 1) for ten seconds. This will reboot (power cycle) the set-top box.

• Avoid mixing up the Ethernet cables in sections 3 and 4.
• If there is a coaxial cable in the cable port (section 2) unscrew it.



Connect the corresponding cables into sections 2 and 3 on your new 5168N.

• Ethernet cables can be connected to any Local Ethernet port (section 2)..
• If you have a coaxial cable connect it to the cable port (section 1).



Go to each individual set-top box, starting with the PVR (VIP1216, VIP2262 or VIP5662). Press and hold the Power button for ten seconds. This will reboot (power cycle) the set-top box.

• If there is a coaxial cable in the cable port (section 2) unscrew it.



Connect the corresponding cables into sections 2 and 3 on your new 5168N.

• Ethernet cables can be connected to any Local Ethernet port (section 3).
• If you have a coaxial cable plug it in the cable port (section 1).



Ensure that you write down the new wireless credentials which are located on the side of the 5168N (section 1). The SSID refers to the new Wireless Network name that you will be connecting to and the Wi-Fi Key is the new wireless password that you will be using.

• If you are using Bell MTS Whole Home Wi-Fi Pods continue to connect to the same Wireless Network name as you did prior.
• If you need help with creating a custom Wi-Fi network click here
• Click on the links if you need help connecting your computer or mobile device to the Wi-Fi.



Go to each individual set-top box, starting with the PVR (VIP1216, VIP2262 or VIP5662). Press and hold the Power button (section 1) for ten seconds. This will reboot (power cycle) the set-top box.

• Avoid mixing up the Ethernet cables in sections 3 and 4.
• If there is a coaxial cable in the cable port (section 2) unscrew it.



Connect the corresponding cables into sections 2 and 3 on your new 5168N.

• Ethernet cables can be connected to any Local Ethernet port (section 2).
• If you have a coaxial cable plug it in the cable port (section 1).



Ensure that you write down the new wireless credentials which are located on the side of the 5168N (section 1). The SSID refers to the new Wireless Network name that you will be connecting to and the Wi-Fi Key is the new wireless password that you will be using.

• If you are using Bell MTS Whole Home Wi-Fi Pods continue to connect to the same Wireless Network name as you did prior.
• If you need help with creating a custom Wi-Fi network click here
• Click on the links if you need help connecting your computer or mobile device to the Wi-Fi.



Go to each individual set-top box, starting with the PVR (VIP1216, VIP2262 or VIP5662). Press and hold the Power button (section 1) for ten seconds. This will reboot (power cycle) the set-top box.
